48
WASHING MACHINE Series GWH / GWM / GWN
INSTALLATION, CONNECTIONS, AND ADJUSTMENTS
ADJUSTMENTS
WARNING!
Adjustment operations must be performed by a certified technician who has been trained by the
Manufacturer.
IMBALANCE MICRO SWITCH ADJUSTMENT (GWH model only)
Adjust the imbalance micro switch to prevent excessive imbalances of the tank drum unit during spinning, and ensure proper
operation of the appliance.
WARNING!
The adjustment operation of the imbalance micro switch must be performed after removing the
transport brackets.
WARNING!
Adjust after installing the appliance in its final position with an empty drum.
Proceed as described:
Step Action
1 Place the elastic rod (A) in the middle and at the bottom with respect to the slot determining the maximum excursion.
A
WARNING!
Adjust this device whenever the appliance must be moved.
To Next Page
