WASHING MACHINE Series GWH / GWM / GWN
INSTALLATION, CONNECTIONS, AND ADJUSTMENTS
ELECTRICAL CONNECTION OF THE LIQUID DETERGENT AUTOMATIC DISPENSING SYSTEM
WARNING!
The appliance electrical connections must be performed by a qualified, enabled technician.
Refer to the wiring diagram for connection modes.
For the electrical connection of the signals controlling the dispensing system, a terminal block for the corresponding pump
connection is provided on the back of the appliance.
The electrical connection plate is located close to the terminal block.
The soap pumps can be powered at 24Vac or 230Vac. The maximum current for the pump control circuit must be powered at 4A.
Proceed as described:
Step Action
1 Run the signal electrical connection cable through the plastic loop.
2 Connect the wires to the respective positions of the connector (screw clamps).
3 Secure the cable by tightening the loop to prevent detachment.
