WASHING MACHINE Series GWH / GWM / GWN
INSTALLATION, CONNECTIONS, AND ADJUSTMENTS
INSTALLATION
WARNING!
Installation must be carried out by a qualified installer trained by the Manufacturer, in the presence
of an electrical technician able to make the electrical connections required.
WARNING!
Any installation changes must be approved by the Manufacturer.
Otherwise, the Manufacturer assumes no liability for injury or damage.
INSTALLATION, CONNECTIONS, AND ADJUSTMENTS
PERMISSIBLE AMBIENT CONDITIONS
The minimum and maximum conditions for the appliance operation are listed below.
Model Power supply
Water pressure
(KPa)
Steam pressure*
(KPa)
Room temperature
(°C)
Room relative
humidity (%)
All models
V Hz Min Max Min Max Min Max Min Max
- 10 < V
< +10 of
the value
stated on
the label.
± 1
compared
to the
value
stated on
the label.
50 800 50 600 5 35
30
without
condensation
90
without
condensation
* only for appliances with this type of heating.
INSTALLATION AND POSITIONING SITE
The installation site must meet the following requirements:
• Be on the ground floor of a building
• have a floor capable of supporting the weight (and the ground efforts indicated in the installation diagrams) of the appliance and
in which a cement screed has been laid
• Have mains connections made in accordance with the applicable regulations of the country of installation.
Holes for the anchor screws of the appliance must be drilled in the installation site (only for GWM / GWN models).
Anchor holes
