GENERAL DESCRIPTION
kg 8 kg 11 kg 14 kg 18 kg 24 kg 28
N (mm) 530 618 618 785 785 785
P (mm) 182 295 295 307 308 308
R (mm) 995 1100 1100 1270 1270 1270
S (mm) 1060 1155 1155 1310 1310 1320
T (mm) 1060 1170 1170 1350 1360 1360
U (mm) 444 444 564 560 695 770
V (mm) 40 35 60 55 55 55
W (mm) 130 130 160 277 141 211
X (mm) 118 118 118 105 105 105
Y (mm) 168 170 89 150 150 150
Z (mm) 375 455 515 670 670 670
