GENERAL DESCRIPTION
kg 8 kg 11 kg 14 kg 18 kg 24 kg 28
A (mm) Width 710 795 795 970 970 970
B (mm) Height 1120 1230 1230 1440 1440 1440
C (mm) 330 410 410 460 460 460
D (mm) 691 691 841 941 941 1086
E (mm) 490 570 570 610 610 610
F (mm) 350 350 350 465 465 465
G (mm) 29 29 29 0 101 0
H (mm) - - - - - -
I (mm) 1035 1148 1148 1336 1336 1336
J (mm) 1035 1132 1132 1293 1293 1293
K (mm) 960 1090 1090 1250 1250 1250
L (mm) 98 98 98 98 98 98
M (mm) 203 203 203 203 203 203
N (mm) 183 293 293 308 308 308
O (mm) 88 100 100 125 125 125
P (mm) 190 250 250 320 320 320
Q (mm) - - - - - -
R (mm) - - - - - -
S (mm) 474 474 574 569 714 789
T (mm) 522 615 615 751 751 751
U (mm) 94 90 90 110 110 110
V (mm) 47 47 47 54 54 54
