P a g e | 21
GDS3710 Input/output Connection Guide
Figure 19: Region Config
Table 3: Motion Detection
Enable Motion Detection
Click on the check box to enable Motion Detection.
Region Config
Click to enter the Region Config menu.
Quit Config
Click to exit the Region Config menu.
Clear Selected Region
Select a zone on the screen then click on Clear to delete the region.
Sensitivity
Region sensitivity ( value between 0-100%).
Select Alarm Schedule
Select the Schedule programmed.
Select Alarm Action Profile
Select the programmed Alarm Action.
 Digit Input
Figure 20: Digit Input
