GDS3710 Input/output Connection Guide
Table 4: Digit Input
Digit Input 1
Select the Input method( alarm Input or Door Open).
Select Alarm Schedule 1
Select the predefined Schedule.
Select Alarm Action Profile 1
Select the predefined Alarm Action.
Digit Input 2
Select the Input method( alarm Input or Door Open).
Select Alarm Schedule 2
Select the predefined Schedule.
Select Alarm Action Profile 2
Select the predefined Alarm Action.
Alarm Output Duration(s) specifies the duration of the output alarm.
Table 5: Alarm Config
Enable Hostage Password
Enable/Disable Hostage password mode.
Hostage password
Set the password for the hostage mode.
Select Alarm Action Profile
Select the Alarm action to be taken when the hostage password is
typed on the GDS3710 keypad.
Note: No sound alarm will be triggered in this mode.
Enable Tamper Alarm
When activating this mode, GDS3710 will keep alarming until the
alarm is dismissed.
Select alarm Action Profile
Select the type of alarms to be taken for the tamper alarm mode.
Enable Keypad Input Error
Alarm
Enable/Disable the Input Error Alarm, GDS3710 will take alarm actions
every 5 incorrect attempts.
Select Alarm Profile
Select the Alarm action to be taken after 5 incorrect attempts.
Notes:
Hostage password can be used in a critical situation for instance a kidnaping or an emergency, users need
to enter the following sequence in order to trigger the actions set for the Hostage Mode:
“* HostagePassword #”.
Tamper alarm is anti-hack from Hardware level. When this option is checked, if the GDS3710 is removed
from the installation board, it will generate the alarm actions configured. There is an embedded mechanism
on the GDS3710 that allow it to sense when the it is removed.
