GRP260x Administration Guide
Version 1.0.1.18
CONFIGURATION GUIDE
This section describes the options in the phone’s Web GUI. As mentioned, you can log in as an
administrator or an end user.
• Status: Displays the Account status, Network status, and System Info of the phone.
• Account: To configure the SIP account.
• Phone Settings: To configure phone general settings, Call Settings, ringtone, Multicast Paging.
• Network Settings: To configure network settings.
• Programmable keys: Configures idle and call screen softkeys, And the Multi-purpose keys settings
for the GRP2604 only.
• System Settings: Configures Time and Language settings, Security Settings, Preferences, TR-069.
• Maintenance: To configure web access, upgrading and provisioning, syslog, language settings, TR-
069, security , Outbound Notifications , Voice monitoring etc.
• Application: Configures Web Service settings, Contacts, LDAP , Call History.
• External Service: Configures GDS Settings, Call Center, BroadSoft XSI.
Status Page Definitions
Table 8: Status Page Definitions
Status → Account Status
Account
Account index.
• For GRP2601/GRP2601P: 2 SIP accounts
• For GRP2602/GRP2602P/GRP2602W: 4 SIP accounts
• For GRP2603/GRP2603P: 6 SIP accounts
• For GRP2604/GRP2604P: 6 SIP accounts
SIP User ID
Displays the configured SIP User ID for the account.
SIP Server
Displays the configured SIP Server address, URL or IP address, and port of
the SIP server.
SIP Registration
Displays SIP registration status for the SIP account, it will display Yes/No
with Green/Red background.
Status → Network Status
MAC Address
Global unique ID of device, in HEX format. The MAC address will be used
for provisioning and can be found on the label coming with original box and
on the label located on the back of the device.
