GRP260x Administration Guide
Version 1.0.1.18
send one at a time for each IP. This behavior lasts if DNS TTL (time-to-live)
is up.
• Saved one until no responses
If the option is set with “Saved one until no responses”, it will send register
messages to the previously registered IP first, but this behavior will persist
until the registered server does not respond.
Configures the primary IP address where the phone sends DNS query to
when "Use Configured IP" is selected for DNS mode.
Configures the backup IP 1 address where the phone sends DNS query to
when "Use Configured IP" is selected for DNS mode.
Configures the backup IP 2 address where the phone sends DNS query to
when "Use Configured IP" is selected for DNS mode.
This parameter configures whether the NAT traversal mechanism is
activated. Users could select the mechanism from No, STUN, Keep-alive,
UPnP, Auto or VPN. The default setting is “Auto”.
If set to “STUN” and STUN server is configured, the phone will route
according to the STUN server. If NAT type is Full Cone, Restricted Cone or
Port-Restricted Cone, the phone will try to use public IP addresses and port
number in all the SIP&SDP messages.
The phone will send empty SDP packet to the SIP server periodically to keep
the NAT port open if it is configured to be “Keep-alive”. Configure this to be
“No” if an outbound proxy is used. “STUN” cannot be used if the detected
NAT is symmetric NAT. Set this to “VPN” if OpenVPN is used.
A SIP Extension to notify the SIP server that the phone is behind a
NAT/Firewall. Do not configure this parameter unless this feature is
supported on the SIP server.
Indicate whether an SBC server is used. If users want to work under SBC
associated with 3CX, they should enable this feature to have better
communication with the server.
Selects whether the phone will send SIP Register messages to the
proxy/server. The default setting is “Enabled”.
