GRP260x Administration Guide
Version 1.0.1.18
Defines the timeout (in seconds) for off-hook auto dial. Valid range is 0-30.
If set to 0, it will be dialed out immediately; If set to other values, it will be
dialed out after the delay.
Off-hook / On-hook
Timeout
If configured, when the phone is in the off-hook or on-hook dialing state, it
will go idle after the timeout (in seconds). Valid range is 10 to 60.
If enable phone will automatically dials out and turns on handsfree mode as
soon as a dial pad key or softkey is pressed.
Set the Live DialPad expire time, interval is between 2s and 15s, default
value is 5s.
Bypass Dial Plan
Through Call History
and Directories
Enable/Disable the dial plan check while dialing through the call history and
any phonebook directories.
Do Not Escape #
as %23 in SIP URI
Specifies whether to replace # by %23 or not for some special situations.
The default setting is “No”.
Return Code When
Refusing Incoming
Call
When refusing the incoming call. The phone will send the selected type of
SIP message of the call. Available options are:
• Busy (486).
• Temporarily Unavailable (480).
• Not found (404).
• Decline (603).
Default setting is “Busy 486”.
Return Code When
Enable DND
When DND is enabled, the phone will send the selected type of SIP
message. Available options are:
• Busy (486).
• Temporarily Unavailable (480).
• Not found (404).
• Decline (603).
Default setting is “Temporarily Unavailable (480)”.
Allow Incoming Call
Before Ringing
This allows incoming calls after dialed but before ringing. This can be used
under custom user configuration based on need.
Configure the prefix in the User-Agent header
Call Progresses
Tones:
• System Ring Tone
Configures ring or tone frequencies based on parameters from local telecom.
The default value is North American standard. Frequencies should be
configured with known values to avoid uncomfortable high pitch sounds.
