FIRMWARE VERSION 1.0.4.23 GXP1400/GXP1405 USER MANUAL Page 34 of 60
"STUN" cannot be used if the detected NAT is symmetric NAT.
SUBSCRIBE for MWI
When set to "Yes", a SUBSCRIBE for Message Waiting Indication will
be sent periodically. The phone supports synchronized and
non-synchronized MWI. The default setting is "No".
SUBSCRIBE for Registration
When set to "Yes", a SUBSCRIBE for Registration will be sent out
periodically. The default setting is "No".
Feature Key Synchronization
This feature is used for Broadsoft call feature synchronization. When it's
enabled, DN
D and Call Forward features can be synchronized with
Broadsoft server. The default setting is "Disabled".
PUBLISH for Presence Enables Presence feature on the phone. The default setting is "No".
Proxy-Require
A SIP Extension to notify the SIP server that
the phone is behind a
NAT/Firewall. Do not configure this parameter unless this feature is
supported on the SIP server.
Voice Mail UserID
Allows
you to access voice messages by pressing the MESSAGE button
on the phone. This ID is usually the VM portal ac
example, in Asterisk server, 8500 could be used.
Send DTMF
Specifies
the mechanism to transmit DTMF digits. There are 3
supported modes: in audio which means DTMF is combined in the audio
signal (not very reliable with low-bit-rate codecs), via RTP (RFC2833), or
via SIP INFO.
DTMF Payload Type
Configures the payload type for DTMF using RFC2833. The default
value is 101.
Early Dial
Selects whether or not to enable early dial. If it's set to "Yes", the SIP
proxy must support 484 response. The default setting is "No".
Dial Plan Prefix Sets the prefix added to each dialed number.
Dial Plan
A dial plan establishes the expected number and pattern of digits for a
telephone number. This parameter configures the allowed dial plan for
the phone.
Dial Plan Rules:
1. Accepted Digits: 1,2,3,4,5,6,7,8,9,0 , *, #, A,a,B,b,C,c,D,d;
2. Grammar: x - any digit from 0-9;
a) xx+ - at least 2 digit numbers
b) xx. - only 2 digit numbers
c) ^ - exclude
d) [3-5] - any digit of 3, 4, or 5
e) [147] - any digit of 1, 4, or 7
