GXP21XX Administration Guide
Displays packet capture status. When user starts to capture trace file, it will
show “RUNNING” status, otherwise, it will show “STOPPED”.
Location where the capture will be stored, either “Internal Storage” or “USB”
Defines whether the packet capture file contains RTP or not. The default
setting is “No”.
Filename of the capture. Only required for USB.
Phonebook Page Definitions
Table 14: Phonebook Page Definitions
Specifies Contact’s First Name, Last Name, Phone Number, Accounts and
Groups to add one new contact in phonebook.
Deletes all contacts from phonebook.
Phonebook Group Management
Specifies Group’s name to add new group.
Phonebook Phonebook Management
Enable Phonebook
XML Download
Configures to enable phonebook XML download. Users could select
HTTP/HTTPS/TFTP to download the phonebook file. The default setting is
"Disabled".
The user name for the HTTP/HTTPS server.
The password for the HTTP/HTTPS server.
Phonebook XML
Server Path
Configures the server path to download the phonebook XML. This field could
be IP address or URL, with up to 256 characters.
Phonebook Download
Interval
Configures the phonebook download interval (in minutes). If it's set to 0, the
automatic download will be disabled. The default value is 0. The valid range
is 5 to 720 minutes.
Remove Manually-
edited Entries on
Download
If set to "Yes", when XML phonebook is downloaded, the entries added
manually will be automatically removed. The default setting is "Yes".
Sort phonebook based on the selection of first name or last name. The
default setting is “Last Name”.
Click on "Download" to download the XML phonebook file to local PC.
Click on "Upload" to upload local XML phonebook file to the phone.
