Table 8: Status page
MAC Address
The device ID, in HEX format. This is very important ID for ISP troubleshooting.
Both LAN and WAN MAC addresses are located here. The LAN MAC address
is used for provisioning and is written on the label in the original box as well as
on the label located on the back panel of the device.
WAN IP Address
This field shows IP address of the HT503.
Product Model
This field contains the product model info, such as HT503.
Software Version
Program: This is the main software release. This number is always used for
firmware upgrade. Current release is 1.0.7.6 Boot and Loader are seldom
changed.
Bootloader: current version is 1.0.0.9.
Core: current version 1.0.7.1
Base: current version is 1.0.7.6
CPE: current version is 1.0.1.19
System Uptime
This shows system up time since last reboot.
PPPoE Link Up
This shows whether the PPPoE is up if connected to DSL modem
NAT
This shows what kind of NAT the HT503 is connected to. It is based on STUN
protocol. If the detected NAT is symmetric NAT, STUN will not work and
Outbound Proxy needed to make HT503 functioning correctly.
Port Status
Displays information regarding the individual FXS ports.
Port
Hook
Registration
DND
Forward
Busy
Forward
Delayed
Forward
FXS
On
Hook
Registered
Yes
613
FXO
Idle
Registered
No
614
