HT503 User Manual
• Both FXS port and FXO port are registered with this SIP Server.
• FXS Port user has set Do Not Disturb.
• FXS Port user has set his calls to be forwarded unconditionally to ext 613.
FXO Port user has set his calls to forward to 614 when his phone is busy.
Table 9: Basic settings
End User Password
This contains the password for end user to access the Web Configuration
Menu. User can put new password here. This field is case sensitive with
maximum of 25 characters
Web Port
This is the device’s internal HTTP server port. Default is 80.
Telnet Server
Default is set to YES. Telnet access is allowed to the device in this case. Used
only for special purposes such as debugging and troubleshooting. List of
available commands will be shown by pressing >help command from telnet
console.
IP Address
• If DHCP mode is enabled, then all the field values for the Static IP mode
are not used (even though they are still saved in the Flash memory.) The
HT503 will acquire its IP address from DHCP in the network.
• PPPoE settings are usually for DSL/ADSL modem users. The HT503 will
attempt to establish a PPPoE session if PPPoE account is set.
• If Static IP mode is selected, the IP address, Subnet Mask, Default Router
IP address, DNS Server 1 (mandatory), DNS Server 2 (optional) fields
need to be configured.
