SLIC chip exception (WARNING and ERROR levels)
memory exception (ERROR level)
The Syslog uses USER facility. In addition to standard Syslog payload, it
contains the following components: GS_LOG: [device MAC address][error
code] error message
Ex. May 19 02:40:38 192.168.1.14 GS_LOG: [00:0b:82:00:a1:be][000]
Ethernet link is up
If Syslog is enabled and Send SIP Log is set to YES, then SIP messages will
also be delivered via Syslog. Default is set to NO.
Download Device
Configuration
This is a special feature that enables the user to create a text file backup of
your existing configuration.
Download Device XML
Configuration
Allows user to download and save a XML file containing all the P values of
each setting as configured at that point on the unit. (Note: For Security
Reasons, all Passwords won’t be Downloaded)
Allows user to upload firmware file from local directory.
Allows user to upload configuration file from local directory.
Table 11: FXS Port settings
When set to yes the FXS port is activated.
This field contains the URL string or the IP address (and port, if different
from 5060) of the SIP proxy server. e.g., the following are some valid
examples: sip.my-voip-provider.com, or sip:my-company-sip-server.com,
or 192.168.1.200:5066
This Field contains the URL or the IP address of a second SIP server, this
To Next Page
