HT503 User Manual
included with the same preference order in SDP message. The first
Vocoder is entered by choosing the appropriate option in “Choice 1”. The
last Vocoder is entered by choosing the appropriate option in “Choice 8”.
Voice Frames per TX
This field contains the number of voice frames to be transmitted in a single
packet. When setting this value, the user should be aware of the requested
packet time (used in SDP message) as a result of configuring this
parameter. This parameter is associated with the first vocoder in the above
vocoder Preference List or the actual used payload type negotiated between
the 2 conversation parties at run time.
Default is 2, from 1 to 4 for G711/G726/G729 only
For example: if this field is set to be 2 and if the first vocoder chosen is
G729 or G711 or G726, then the “ptime” value in the SDP message of an
INVITE request will be 20ms (2 x10ms)
If the configured voice frames per TX exceeds the maximum allowed value,
the ATA will not accept it and will use and save the precedent configured
allowed value for the corresponding first vocoder choice.
G723 Rate
This defines the encoding rate for G723 vocoder. Default setting is 6.3kbps.
iLBC Frame Size
This sets the iLBC size in 20ms or 30ms
iLBC Payload Type
This defines payload type for iLBC. Default value is 97. The valid range is
between 96 and 127.
AAL2-G726-16
Payload Type
Defines payload type for AAL2-G726-16. Default value is 100. Range is
from 96 to 127.
AAL2-G726-24
Defines payload type for AAL2-G726-24. Default value is 99. Range is
