HT802 User Guide
HT802 LEDs Pattern
There are four (4) LED buttons that help you manage the status of your Handy Tone 802.
Figure 4: HT802 LEDs Pattern
Table 3: HT802 LEDs Pattern Description
LED Lights
Status
Power LED
The Power LED lights up when the HT802 is powered on and it flashes when
the HT802 is booting up.
Internet LED
The Ethernet LED lights up when the HT802 is connected to your network
through the Ethernet port and it flashes when there is data being sent or
received.
Phone LED 1&2
The phone LED 1 & 2 indicates status of the respective FXS Ports-phone on
the back panel
 OFF - Unregistered
 ON (Solid Blue) - Registered and Available
 Blinking every second - Off-Hook / Busy
 Slow blinking - FXS LEDs indicates voicemail
