2
Installation
Cards
Cards
The table below indicates how the cards are distributed in the Kaleido-MX (3RU)
housing frame:
Available Options
• Second power supply for redundant power security
• Second GPI-1501 GPI I/O module
• REF-1801 HD/SD frame reference module
Seamless
control across
multiple
multiviewers
Kaleido multiviewers can be mixed and matched to create a seamless
monitoring system across a facility.
Choice of control options such as the standalone Kaleido-RCP2 or RCP-200
panels, integrated with router control systems and panels, iControl, and
third-party control systems.
Superior layout
flexibility
Unlimited signal repetition at any sizes across all displays, without blocking,
grouping restrictions or bandwidth restrictions.
Router and
switcher
integration
The Kaleido-MX integrates with the NVISION router family, and third-party
routers and production switchers for tally and label/alias source
management. Multiple multiviewers can be controlled from a single control
panel.
Scalable for the
largest systems
Virtually limitless multiviewer system expansion with upstream NVISION
router. A combined multiviewer/router system may include up to 1152 video
inputs, and 288 multiviewer outputs.
Kaleido-MX features (continued)
Slot Card Card model Applies to...
1 GPI I/O 1 GPI-1501 All 3RU configurations
2 GPI I/O 2 GPI-1501 All 3RU configurations (optional)
4 Input D KMX-3901-IN-16-Q 64 × 4
KMX-3901-IN-16-D
64 × 2
7 Input C KMX-3901-IN-16-Q 48 × 4, 64 × 4
KMX-3901-IN-16-D
48 × 2, 64 × 2
9 Reference VDA-1002 All 3RU configurations
10 URS REF-1801 All 3RU configurations (optional)
12 Input B KMX-3901-IN-16-Q 32 × 4, 48 × 4, 64 × 4
KMX-3901-IN-16-D
32 × 2, 48 × 2, 64 × 2
15 Input A KMX-3901-IN-16-Q 32 × 4, 48 × 4, 64 × 4
KMX-3901-IN-16-D
32 × 2, 48 × 2, 64 × 2
17 Output B KMX-3901-OUT-D 32 × 4, 48 × 4, 64 × 4
19 Output A KMX-3901-OUT-D All 3RU configurations
