WIRING DIAGRAM - 623T
Item Order Description
No. No.
Item Order Description
No. No.
02-14083A / 01-14084
Rev. 11-16
606857 Wiring Assembly - 623T
161092 Decal - Console
1 183806 Ignition Switch
254498 Nylon Nut - Ignition Switch
2 182326 Indicator Light - Brake
3 184179 Light Switch (optional)
4 183925 Clutch Switch
5 183860 Safety Switch - Rt. Steering
720160 Rt. Steering Switch Mount
6 183860 Safety Switch - Lt. Steering
720161 Lt. Steering Switch Mount
7 183871 Seat Safety Switch
8 182261 Worklamp LED Flood (optional)
(includes item 9)
9 182251 Bezel (optional)
10 182327 Indicator Light - Oil
11 184271 Relay w/Mount
12 181722 Fuse Block
162320 Fuse I.D. Decal
13 181470 Fuse 30 Amp Auto
181462 Fuse 10 Amp Auto
181460 Fuse 7.5 Amp Auto
14 141551 Hour Meter
15 183894 Brake Switch
16 180125 Battery 12 Volt
644099 Battery Box
644162 Battery Cover
17 729001 Battery Clamp
18 181735 Fuse Holder
181470 Fuse 30 Amp Auto
19 423690 Spacer - PC Board Support
20 180276 Battery Cable 16" Black
21 180315 Battery Cable 16" Red
425219 Battery Terminal Boot
22 388840 Cable Assembly
23 184936 Connector - 4 Way
24 422072 Hole Plug
START
ON
OFF
OFF
RUN
161092
IGNITION
PULL OUT TO ENGAGE
PTO CLUTCH
LIGHTS
1
10
4
14
3
2
24
