5
SPECIFICATIONS
623T
Engine Kohler Command, two cylinder, 4 cycle, air cooled
Model No. CH682
Displacement 42.3 cu. in. (694 cc.)
No-load r.p.m. 3600
Charging System 12 VDC 15 amp.
negative ground
Starter Electric
Electrical System Safety interlocked
PTO 3100 r.p.m. (max.)
Electric clutch
Drive System Tandem hydrostatic transmission direct drive
Steering Dual levers independently control speed and direction of travel
Zero turning radius (center of machine is pivot point)
Speed
Forward (variable) 0 to 8.5 m.p.h. (13.7 km/h)
Reverse (variable) 0 to 6.0 m.p.h. (9.6 km/h)
Fuel Tank Capacity 4.0 U.S. gal. (15.1 liter)
Tire Sizes
Front Drive Wheels 20 x 10 x 8
Tail Wheel 13 x 6.50 x 6 rib
Dimensions of Tractor
Seat Back Height 44.5" (1.13 m.)
Seat Cushion Height 28" (.71 m.)
Tractor Width 47" (1.19 m.)
Tractor Length 75" (1.91 m.)
Wheel Base 46" (1.17 m.)
Weight - Uncrated 750 lbs. (340 kg.)
Weight - Crated 895 lbs. (406 kg.)
Hour Meter Standard
Rev 12-16
