13 / 32
S3084_S3086_S3078_S3085_MP_V1
Settable values in the program
Programmable
Items
Parameter Values Default
Motor Type Sensor only for S3084,S3086,S3078 Hybrid only for S3078,S3086,S3085 Sensor
Select Battery LiPo / LiFe / NiMH (NiCd) LiPo
Cut Off Voltage
Disable / Auto / 3.0V ~ 7.5V (Step:0.1V)
Disable / Auto / 6.0V ~ 23V (Step:0.1V)_S3085
Auto
Power Curve 0 ~ 10 5
Boost Max+TB
Boost Max + TB
Off X X
ON 0 ~ 58 (Hybrid:25) 0 ~ 58 (Hybrid:25)
+TH 0 ~ 58 (Hybrid:25) 0 ~ 58 (Hybrid:25)
Off
Boost Min-rpm 0 ~ 64500 (Step: 500 rpm) 5000 rpm
Boost Max-rpm 0 ~ 65000 (Step: 500 rpm)
25000
rpm
Boost-TH. Limit
TH Limit
20% 0 ~ 58 (Hybrid:25)
40% 0 ~ 58 (Hybrid:25)
60% 0 ~ 58 (Hybrid:25)
80% 0 ~ 58 (Hybrid:25)
100% 0 ~ 58 (Hybrid:25)
0
Turbo Delay 0.00 ~ 1.00s (Step: 0.05s) 0.20s
Turbo + Slope 0.00 ~ 1.00s (Step: 0.05s) 0.20s
Turbo - Slope 0.00 ~ 1.00s (Step: 0.05s) 0.20s
Acceleration 0 ~ 10 5
Start Power 0 ~ 100 (Step: 1%) 0%
Start Curr Limit Off, 1% ~ 100% (Step: 1%) Off
Current Limit Off, 1% ~ 100% (Step: 1%) Off
Reverse Function One Way / Two Way / Two Way 2 / Two Way 3 One Way
Reverse Delay Off / 0.2s / 0.5s / 0.8s / 1.3s / 1.8s / 2.5s 2.5s
M-Reverse Amount 20 ~ 100% (Step: 1%) 100%
Neutral Width Narrow / Normal / Wide Wide
Motor Direction Normal / Reverse Normal
Brake Response 0% ~ 100% (Step: 1%) 0%
A.B.S. Brake Off / Weakest / Weak / Normal / Strong / Strongest Off
Drag Brake 0% ~ 100% (Step: 1%) 0%
Min Brake Amount 0% ~ 100% (Step: 1%) 30%
Mid Brake Amount 0% ~ 100% (Step: 1%) 50%
Mid Brake Location 0% ~ 100% (Step: 1%) 50%
Max Brake Amount 0% ~ 100% (Step: 1%) 100%
Soft Brake Hard / Soft Soft Soft
Brake Freq 1KHz / 2KHz / 5KHz / 8KHz / 16KHz / 32KHz 1KHz
Motor Freq 1KHz / 2KHz / 5KHz / 8KHz / 16KHz / 32KHz 8KHz / 16KHz 5KHz
Drag Freq 1KHz / 2KHz / 5KHz / 8KHz / 16KHz / 32KHz 1KHz
Cut Off Temp 100° ~ 135° (Step: 5) / Disable 135°
Cut Off M-Temp 100° ~ 135° (Step: 5) / Disable 135°
B.E.C. Voltage 6.0 / 7.4V 6.0V
Current Voltage XX.X
Current Temp 100° ~ 135°
Max Temperature 100° ~ 135°
Motor Temp 100° ~ 135°
Motor Max Temp 100° ~ 135°
Max Current 0 A ~ 999 A
Motor Pole Num 2 ~ 20 Pole 2 Pole
Gear ratio 2.0 : 1 ~ 15.0 : 1 2.0 : 1
Tire Diameter 40mm ~ 200mm 63mm
Motor-Wiring A-B-C / C-B-A A-B-C
Maximum Speed XXX.X Km/h
Maximum RPM XXX rpm
Error History M, T1, T2, S, V, R
Download All parameters inside the setup card are downloaded to the ESC.
Restore Memory All setting information inside EEPROM are read via the RAM.
Backup Memory All setting information inside the RAM are stored at EEPROM
Factory Setting Change the setting of ESC to default status.
