GRAUPNER GENIUS PRO 60R for W-Lan - ESC Data View in Telemetry

15 / 32
S3084_S3086_S3078_S3085_MP_V1
LED error display
(R) No receiver signal - the red LED flashes 1x/sec
(V) Battery voltage too low - the red LED flashes 2x/sec
(S) Sensor problem - the red LED flashes 3x/sec
(T1) Speed controller temperature too high - the red LED flashes 4x/
sec
(M) Motor problem - the red LED flashes 5x/sec
(T2) Motor temperature too high - the red LED flashes 6x/sec
LED status display
Throttle position Green LED Red LED
Neutral On Off
Neutral (0-boost) flashes Off
Full throttle Off On
Full braking On On
ESC data view in the telemetry menu
Telemetry data
display on a Graupner / SJ HOTT transmitter
Current: MAX, Actual current
Volt: MIN, Actual voltage
ESC: MAX temp Actual temperature
MOTOR:( motor temp.) MAX temp. , Actual temperature
SPEED(MAX): MAX SPEED(KM/H) Maximum speed
SPEED(AVG): AVG SPEED(KM/H) Average speed
ERROR : M T1 T2 V R S (see error list above)
[ESC] DATA VIEW <>
Curr : 5.3Max 3.0A
Volt : 7.5Min 7.6V
ESC : 29
°
Max 28
°
C
MOTOR : 29
°
Max 28
°
C
SPEED(MAX):000.0km/h
SPEED(Avg):000.0km/h
ERROR : M T1 T2 V R S
