Setting the throttle travel
Note
This initial adjustment of the throttle lever is only necessary if you
use another transmitter or if the settings have been changed.
Switch on the transmitter ("ON"), then place the throttle lever in the
"neutral" position and stop. The throttle and brake on the transmit-
ter should be set to 100.
Connect the battery to the controller, making sure the polarity is
correct. Switch on the controller. Once all connecting cables are
connected properly, the motor generates a short beep to indicate
that the power supply is connected.
Now press the push button for longer than 1 second. The green LED
flashes. Upon releasing the push button, the green LED starts to
glow and the neutral point is saved.
Now open the throttle completely. The red LED starts to glow; the
full throttle position is saved.
Now apply the brake fully. Both LEDs start to glow; the full braking
position is saved.
Now return the throttle to neutral. The red and green LEDs flash and
signal successful completion of transmitter adjustment.
