GRAUPNER JULES VERNE - Parts List

GRAUPNER GmbH & Co. KG D-73230 KIRCHHEIM/TECK GERMANY
Keine Haftung für Druckfehler. Technische Änderungen vorbehalten! ID# 47496 10/2003
27
Parts List
No. Part Description No. off Material Dimensions and thickness in mm
1 Boatstand side panel 4 Plywood Die-cut, 4.0 mm
2 Boatstand front support 2 Plywood Die-cut, 4.0 mm
3 Boatstand rear support 2 Plywood Die-cut, 4.0 mm
4 Hull 1 ABS Vac. moulded, 2.0 mm, CNC-trimmed
5 Rudder bush 2 Brass 4 / 3.2 Ø x 25 mm
6 Rudder unit 2 - Ready made
7 Tiller 2 Plastic Ready made
8 Collet 2 Plated brass Ready made
9 Retaining screw 2 Metal M3 x 6 mm
10 Rudder link rod 1 Steel rod 1.5 mm Ø, 85 mm
11 Pushrod keeper 3 Plastic Ready made
12 Rudder pushrod 1 Steel rod 1.5 mm Ø, overlength
13 Servo mount 1 ABS Vac.-moulded, 1.0 mm
14 Servo 1 - e.g. Order No. 4101
15 Pushrod connector 1 - Ready made
16 Retaining nut 1 Plastic M2
17 Grubscrew 1 Browned steel M3 x 3 mm
18 Stern tube 2 Metal Ready made
19 Bracket 2 Plastic Ready made
20 Retaining screw 4 Steel 2.2 Ø x 6.5 mm
21 Shaft coupling 2 Aluminium Ready made
22 Grubscrew 8 Browned steel M3 x 3 mm
23 Motor 2 - Order No. 3302
24 Motor mount 2 Plastic Ready made
25 Motor retaining screws 4 Browned steel M3 x 3 mm
26 Retaining screw + nut 4 Metal M2 x 6 mm + M2
27 Suppressor capacitor 2 - Order No. 3588
28 Motor power cable 2 - Order No. 3389 + 2989
29 Motor mount braces 4 Spruce 10 x 10 mm, oversize
30 Retaining screw 4 Steel 2.2 Ø x 13 mm
31 Propeller 2 Plastic 32.5 mm Ø, R.H. / L.H.
32 Fin strake 1 ABS Vac.-moulded, 2.0 mm
33 Stern staircase 1 ABS Vac.-moulded, 2.0 mm, CNC-trimmed
34 Bow thruster (optional) 1 - Order No. 1785
35 RC plate 1 Plywood Die-cut, 4.0 mm
36 Deck 1 ABS Vac.-moulded, 2.0 mm, CNC-trimmed
37 Lower rubbing strake 2 ABS 3 x 3 x 300 mm, square strip
38 Upper rubbing strake 2 ABS 3 x 3 x 72 mm, square strip
39 Wooden deck 1 Plywood Laser-processed, 1.0 mm
40 Ornamental lining 2 Plywood Laser-processed, 1.0 mm
41 Rubbing strake 3 ABS 3.2 x 1.5 mm, half-round, overlength
42 Staircase treads 8 Plywood Laser-processed, 1.0 mm
43 Wooden bathing platform deck 1 Plywood Laser-processed, 1.0 mm
44 Superstructure 1 ABS Vac.-moulded, 1.0 mm, CNC-trimmed
45 Side cladding 2 Plywood CNC-machined, 1.0 mm
