Gravely ZT2352 User Manual

30 pages

To Next Page

To Next Page

Page #1 background image

Loading...

Page #1 background image

Owner/Operator Manual

Models

915042 - ZT1540

915044 - ZT1740

915046 - ZT1944

915048 - ZT2148

915050 - ZT2352

ZT

00296000C 5/04

Supersedes 00296000, A-B

Printed in USA

Transfer

model &

serial number

label from

product reg-

istration here.

Coller l’autocollant du

modèle et du numéro de

série dans cet encadré.

Transferir aquí la etiqueta del

modelo y número de serie

del registro del producto.

ENGLISH

FRANÇAIS

ESPAÑOL

Table of Contents

Questions and Answers:

K
kwangAug 19, 2025
Why won't my Gravely ZT2352 engine crank/start?
- A
  Angela BarnettAug 19, 2025
  If your Gravely Lawn Mower engine won't crank or start, it could be due to several reasons. First, make sure the safety interlock system is properly engaged and not faulty. Next, ensure the fuel tanks are filled and the fuel shut-off valve is open. Check the battery; if it's discharged, charge it. Also, verify that the battery cables are tightly connected and clean. Inspect the spark plug wires to ensure they are connected, and the spark plugs aren't faulty. If these steps don't resolve the issue, it could be a faulty electrical system or engine, in which case you should contact your Gravely Dealer.
S
Samantha JohnsonAug 21, 2025
Why won't my Gravely ZT2352 Lawn Mower engine crank or start?
- M
  Melissa WilliamsAug 21, 2025
  There are several reasons why your Gravely Lawn Mower engine might not crank or start: * The safety interlock system may not be engaged or could be faulty. * The fuel tanks might be empty; if so, fill them. * The fuel shut-off valve may be closed; open it. * The battery could be discharged; charge it. * There might be a poor connection between the battery and battery cables; tighten the cables and/or clean the battery and cables. * The spark plug wire(s) may be loose, or the spark plug(s) may be faulty; connect the wire(s) or replace the plug(s).
C
cmcfarlandAug 23, 2025
What to do if PTO or mower blades do not engage or shut off on my Gravely ZT2352?
- M
  Michael HollowayAug 23, 2025
  If the PTO or mower blades on your Gravely Lawn Mower do not engage or shut off, there are several potential causes. Ensure the operator presence switch is depressed by sitting on the seat. Check if the electric clutch connector is loose or disconnected, and connect it if necessary. A faulty PTO belt could also be the problem, so consider replacing it. If your model is 915044, 046, 048, or 050, the electric clutch may need adjustment. If these steps don't resolve the issue, it could be a faulty operator presence switch, PTO switch, wires, connectors, or clutch, in which case you should contact your Gravely Dealer.
B
brianjacksonAug 26, 2025
How to improve the cutting quality of my Gravely Lawn Mower?
- W
  William JensenAug 26, 2025
  If you're experiencing poor cutting quality with your Gravely Lawn Mower, it could be due to a couple of issues. First, check if the mower deck is level and the mower pitch is correct, and adjust if necessary. Also, inspect the mower blades; if they are dull or faulty, sharpen or replace them.
M
Matthew SmithAug 27, 2025
What to do if my Gravely ZT2352 does not move with engine running?
- J
  Joshua NelsonAug 27, 2025
  If your Gravely Lawn Mower doesn't move when using the steering levers with the engine running, it could be due to a few reasons. First, check if the transmission bypass lever is engaged and disengage it. Another potential cause is a faulty hydrostatic belt, which should be replaced. If the issue continues, it might be a faulty transmission, and you should contact your Gravely Dealer.
A
Angelica ThomasAug 30, 2025
What to do if my Gravely ZT2352 PTO or mower blades do not engage or shut off?
- R
  Ronald JonesAug 30, 2025
  If the PTO or mower blades on your Gravely Lawn Mower do not engage or shut off, consider the following: * Ensure the operator presence switch is depressed by sitting on the seat. * Check if the electric clutch connector is loose or disconnected, and connect it if necessary. * Inspect the PTO belt for faults and replace it if needed.
S
Sara GilmoreSep 1, 2025
What to do if my Gravely ZT2352 unit does not move with engine running when using steering levers?
- H
  hudsonjohnSep 1, 2025
  If your Gravely Lawn Mower doesn't move when using the steering levers while the engine is running, it could be because: * The transmission bypass lever is engaged; disengage it. * The hydrostatic belt is faulty; replace it.
O
obauerSep 3, 2025
How to fix poor cutting quality on my Gravely ZT2352 Lawn Mower?
- M
  Michael RojasSep 3, 2025
  If you're experiencing poor cutting quality with your Gravely Lawn Mower, consider these points: * The mower deck may not be level, or the mower pitch is incorrect; level and adjust the pitch of the mower deck. * The mower blades may be dull or faulty; sharpen or replace them.
K
Keith AndersonSep 5, 2025
How to fix a Gravely Lawn Mower engine that runs rough?
- A
  Anthony WolfeSep 5, 2025
  If your Gravely Lawn Mower engine runs rough, it might be due to a few reasons. First, check if the choke is engaged and disengage it. Another common cause is a plugged air filter cartridge, which should be cleaned or replaced. If the problem persists, it could be a faulty engine, and you should contact your Gravely Dealer.
R
Ruth AndrewsSep 7, 2025
Why is my Gravely ZT2352 Lawn Mower engine overheating?
- R
  Rebecca ReynoldsSep 7, 2025
  If your Gravely Lawn Mower engine overheats, it could be due to a few reasons. First, check the engine oil level and add oil if it's low. Another potential cause is a plugged cooling system, which should be cleaned. If the issue persists, it could indicate a faulty engine, and you should contact your Gravely Dealer.

Gravely ZT2352 Specifications

General

Engine Type	Kawasaki FR691V
Horsepower	23 HP
Cutting Width	52 inches
Cutting Deck	Fabricated
Speed	8.5 mph forward / 4 mph reverse
Deck Lift	Foot Operated
Cutting Height Range	1.5 - 4.5 in

Summary

Owner/Operator Manual

Safety Guidelines and Precautions

Pre-Operation Safety Checks

Understanding Safety Alerts

Explains the meaning of safety alert symbols used in the manual and on decals.

Safety Hazard Levels

Defines the severity levels of safety messages: Danger, Warning, and Caution.

Safety Decals and Associated Warnings

Decals 2 & 3: Rotating Parts and Fuel Dangers

Highlights dangers associated with rotating parts and fuel handling.

Decal 4: Guard/Bagger Operation Warning

Decal 5: Critical Injury/Death Warnings

Provides critical safety instructions for avoiding serious injury or death.

General Safety Rules and Hazards

Specific Operational Hazards

Details specific hazards like discharge, backing, children, slopes, and hot surfaces.

Core Safety Rules for Operation

Outlines essential safety rules for operation, maintenance, and general use.

Safe Operating Practices

Operator Responsibilities and Protective Gear

Covers operator qualifications, alertness, protective gear, and handling sharp/moving parts.

Slope Operation and Stability

Provides detailed guidance on operating safely on slopes, including speed and turning.

Maintenance and Fuel Handling Safety

Transporting and Fuel Safety Practices

Details safe practices for handling fuel, filling tanks, and transporting the unit.

Electrical and Battery Safety

Covers battery safety, connections, charging, and avoiding electrical hazards.

General Maintenance Safety Warnings

Assembly and Initial Setup Procedures

Controls and Safety Interlock System

Control Identification and Location

Identifies and locates all controls and features using Figure 4.

Safety Interlock System Verification

Explains the safety interlock system and provides tests to verify its proper function.

Detailed Control Operation

Ignition, Brake, and Fuel Controls

Throttle, PTO, and Steering Controls

Operating Procedures and Manual Movement

Engine Starting and Stopping

Provides step-by-step instructions for starting and stopping the engine.

Maintenance Schedule and Procedures

Each Use Maintenance Checks

Lists critical checks and tasks to perform before or after each use.

Safety Interlock System Verification

Emphasizes testing the safety interlock system before each operation.

Service and Adjustments

Hood and Mower Deck Removal

Mower Deck Removal Procedure

Step-by-step instructions for removing the mower deck.

Mower Deck Leveling and Pitch Adjustment

Leveling the Mower Deck

Adjusting Mower Deck Pitch

Mower Blade Service Procedures

Mower Blade Replacement Process

Blade Sharpening and Balance Checks

Battery Servicing and Cleaning

Battery Removal and Installation

Battery Cable Cleaning Procedure

Belt and Electric Clutch Service

Hydrostatic Belt Replacement

Electric Clutch Testing and Adjustment

Explains how to test and adjust the electric clutch for proper blade stopping.

Electric Clutch Adjustment and Storage

Adjusting Electric Clutch Air Gap

Testing Electric Clutch Functionality

Procedures to test the electric clutch function after adjustment.

Troubleshooting Engine and Drive Issues

Engine Starting Problems

Lists probable causes and corrections for engine starting issues.

Engine Performance Issues

Drive System Problems

Troubleshoots problems related to unit movement and PTO/blade engagement.

Troubleshooting Chassis and Cutting Issues

Parking Brake and Tracking Problems

Cutting Quality Issues

Technical Specifications

Engine and Performance Specifications

Dimensions, Weight, and Tire Specifications

Provides dimensions, weight, tire information, and mower deck specifications.

Limited Warranty Details

Warranty Coverage and Conditions

Outlines the terms, conditions, and duration of the limited warranty.

Warranty Exclusions and Limitations
