Owner/Operator Manual
Models
915042 - ZT1540
915044 - ZT1740
915046 - ZT1944
915048 - ZT2148
915050 - ZT2352
ZT
00296000C 5/04
Supersedes 00296000, A-B
Printed in USA
Transfer
model &
serial number
label from
product reg-
istration here.
Coller l’autocollant du
modèle et du numéro de
série dans cet encadré.
Transferir aquí la etiqueta del
modelo y número de serie
del registro del producto.
ENGLISH
FRANÇAIS
ESPAÑOL

Table of Contents

Questions and Answers

  • A
    Amy HurleyAug 19, 2025
    Why won't my Gravely ZT2148 engine crank/start?
    • A
      Alan TurnerAug 19, 2025
      If your Gravely Lawn Mower engine won't crank or start, it could be due to several reasons. First, make sure the safety interlock system is properly engaged and not faulty. Next, ensure the fuel tanks are filled and the fuel shut-off valve is open. Check the battery; if it's discharged, charge it. Also, verify that the battery cables are tightly connected and clean. Inspect the spark plug wires to ensure they are connected, and the spark plugs aren't faulty. If these steps don't resolve the issue, it could be a faulty electrical system or engine, in which case you should contact your Gravely Dealer.
  • A
    ashley23Aug 21, 2025
    Why won't my Gravely ZT2148 engine crank or start?
    • H
      halldeniseAug 21, 2025
      There are several reasons why your Gravely Lawn Mower engine might not crank or start: * The safety interlock system may not be engaged or could be faulty. * The fuel tanks might be empty; if so, fill them. * The fuel shut-off valve may be closed; open it. * The battery could be discharged; charge it. * There might be a poor connection between the battery and battery cables; tighten the cables and/or clean the battery and cables. * The spark plug wire(s) may be loose, or the spark plug(s) may be faulty; connect the wire(s) or replace the plug(s).
  • J
    Juan WilsonAug 25, 2025
    What to do if PTO or mower blades do not engage or shut off on my Gravely Lawn Mower?
    • R
      Raymond WhiteAug 25, 2025
      If the PTO or mower blades on your Gravely Lawn Mower do not engage or shut off, there are several potential causes. Ensure the operator presence switch is depressed by sitting on the seat. Check if the electric clutch connector is loose or disconnected, and connect it if necessary. A faulty PTO belt could also be the problem, so consider replacing it. If your model is 915044, 046, 048, or 050, the electric clutch may need adjustment. If these steps don't resolve the issue, it could be a faulty operator presence switch, PTO switch, wires, connectors, or clutch, in which case you should contact your Gravely Dealer.
  • T
    Tracey SmithAug 26, 2025
    How to improve the cutting quality of my Gravely ZT2148 Lawn Mower?
    • S
      Steven FieldsAug 26, 2025
      If you're experiencing poor cutting quality with your Gravely Lawn Mower, it could be due to a couple of issues. First, check if the mower deck is level and the mower pitch is correct, and adjust if necessary. Also, inspect the mower blades; if they are dull or faulty, sharpen or replace them.
  • C
    cody54Aug 28, 2025
    What to do if my Gravely ZT2148 Lawn Mower does not move with engine running?
    • Y
      ypopeAug 28, 2025
      If your Gravely Lawn Mower doesn't move when using the steering levers with the engine running, it could be due to a few reasons. First, check if the transmission bypass lever is engaged and disengage it. Another potential cause is a faulty hydrostatic belt, which should be replaced. If the issue continues, it might be a faulty transmission, and you should contact your Gravely Dealer.
  • F
    Frank LucasAug 30, 2025
    What to do if my Gravely ZT2148 Lawn Mower PTO or mower blades do not engage or shut off?
    • R
      Robert MartinAug 30, 2025
      If the PTO or mower blades on your Gravely Lawn Mower do not engage or shut off, consider the following: * Ensure the operator presence switch is depressed by sitting on the seat. * Check if the electric clutch connector is loose or disconnected, and connect it if necessary. * Inspect the PTO belt for faults and replace it if needed.
  • N
    Nicholas NelsonSep 1, 2025
    What to do if my Gravely Lawn Mower unit does not move with engine running when using steering levers?
    • J
      james09Sep 1, 2025
      If your Gravely Lawn Mower doesn't move when using the steering levers while the engine is running, it could be because: * The transmission bypass lever is engaged; disengage it. * The hydrostatic belt is faulty; replace it.
  • D
    David EllisSep 3, 2025
    How to fix poor cutting quality on my Gravely Lawn Mower?
    • K
      kathryn44Sep 3, 2025
      If you're experiencing poor cutting quality with your Gravely Lawn Mower, consider these points: * The mower deck may not be level, or the mower pitch is incorrect; level and adjust the pitch of the mower deck. * The mower blades may be dull or faulty; sharpen or replace them.
  • W
    wilkersonvictorSep 5, 2025
    How to fix a Gravely Lawn Mower engine that runs rough?
    • P
      Paige FernandezSep 5, 2025
      If your Gravely Lawn Mower engine runs rough, it might be due to a few reasons. First, check if the choke is engaged and disengage it. Another common cause is a plugged air filter cartridge, which should be cleaned or replaced. If the problem persists, it could be a faulty engine, and you should contact your Gravely Dealer.
  • M
    Megan GrahamSep 7, 2025
    Why is my Gravely ZT2148 engine overheating?
    • R
      Renee JohnsonSep 8, 2025
      If your Gravely Lawn Mower engine overheats, it could be due to a few reasons. First, check the engine oil level and add oil if it's low. Another potential cause is a plugged cooling system, which should be cleaned. If the issue persists, it could indicate a faulty engine, and you should contact your Gravely Dealer.

Summary

SAFETY

SAFETY ALERTS

Explains the meaning of safety alert symbols (!, DANGER, WARNING, CAUTION) for hazard recognition.

SAFETY DECALS AND LOCATIONS

Emphasizes replacing decals and refers to Figure 2 for their locations on the unit.

SAFETY RULES

ASSEMBLY

PLACE UNIT IN OPERATING POSITION

Steps to set up the unit for operation, including seat and steering lever installation.

FILL FUEL TANKS

CHECK FUNCTION OF ALL CONTROLS

Directs the user to the Operation section to verify all controls function correctly.

CONTROLS AND FEATURES

CONTROLS AND FEATURES OVERVIEW

Identifies and locates all controls and features of the mower, referencing Figure 4.

SAFETY INTERLOCK SYSTEM FUNCTIONALITY

Details tests to ensure the safety interlock system is functioning properly for safe operation.

OPERATING PROCEDURES

FILLING THE FUEL TANKS

STOPPING IN AN EMERGENCY

Procedure to quickly and safely stop the unit and engine in an emergency situation.

STARTING AND SHUTTING OFF ENGINE

Detailed steps for starting the engine, including choke and throttle usage, and shutting it down.

OPERATING MOWER

Steps for starting the engine, engaging the PTO, and moving the unit with steering levers.

MAINTENANCE SCHEDULE

CHECK SAFETY INTERLOCK SYSTEM

Reminder to test the safety interlock system each time the unit is operated for safety.

CHECK PARKING BRAKE

CHECK MOWER BLADES

SERVICE AND ADJUSTMENTS

CHECK MOWER BLADE STOPPING TIME

Refers to testing the time it takes for mower blades to stop after PTO disengagement.

MOWER DECK LEVELING AND ADJUSTMENT

LEVEL MOWER DECK

ADJUST PITCH OF MOWER DECK

MOWER BLADE SERVICE

SHARPENING MOWER BLADE

CHARGING AND STARTING PROCEDURES

STEERING LEVER ADJUSTMENTS

ADJUSTING STEERING LEVERS TO MATCH

ADJUSTING HEIGHT OF STEERING LEVERS

HANDLEBAR AND BELT MAINTENANCE

PTO BELT REPLACEMENT

Detailed steps for removing and installing the PTO belt, including idler spring tension care.

HYDROSTATIC BELT REPLACEMENT

ELECTRIC CLUTCH ADJUSTMENT

TEST MOWER BLADE STOPPING TIME

How to test if mower blades stop within the specified time after PTO disengagement.

ADJUST ELECTRIC CLUTCH

Guidance on checking and adjusting the electric clutch air gap for proper engagement/disengagement.

TROUBLESHOOTING

ENGINE WILL NOT CRANK;START

Lists probable causes and corrections for issues preventing the engine from cranking or starting.

ENGINE RUNS ROUGH

Identifies potential causes like choke or air filter issues, and their corresponding solutions.

UNIT DOES NOT MOVE WITH ENGINE RUNNING

Troubleshooting steps for when the unit fails to move, related to transmission bypass or belt issues.

PTO OR MOWER BLADES DO NOT ENGAGE OR SHUTS OFF

Covers issues with PTO engagement, blade operation, and shutdown, linking to belt and clutch adjustments.

ENGINE OVERHEATS

Addresses engine overheating due to low oil or plugged cooling systems, referencing the Engine Manual.

ADDITIONAL TROUBLESHOOTING

UNIT MOVES WITH ENGINE OFF AND PARKING BRAKE ENGAGED

Troubleshooting faulty parking brake adjustment or function.

UNIT DOES NOT TRAVEL IN A STRAIGHT LINE

UNIT CREEPS WITH STEERING LEVERS IN NEUTRAL LOCKOUT POSITION

POOR CUTTING QUALITY

Troubleshooting poor cutting quality, focusing on deck leveling and blade sharpness/condition.

SPECIFICATIONS

Gravely ZT2148 Specifications

General IconGeneral
Engine Displacement726 cc
Cutting Width48 inches
Fuel Capacity3.5 gallons
Cutting Height1.5 - 4.5 inches
Spindle MaterialAluminum
Warranty3 years
Deck MaterialSteel
Blade Tip Speed18, 000 ft/min
Turning RadiusZero-Turn
