Gree FB01 - Outline Dimension

D Series Modular Air-cooled Scroll Chillers
7
3 Outline Dimension
(1) Graph for the shape and dimensions for LSQWRF65M/NaD-M(FB01)
(Unit:mm)
1000
2160
2040
1396
238
319
1750(Ground bolt 4-M12)
967(Ground bolt)
(2) Graph for the shape and dimensions for LSQWRF130M/NaD-M(FB01)
(Unit:mm)
2226
1676
2026(Ground bolt 4-M12)
1617(Ground bolt 4-M12)
1650
2160
323
366
