Super Free Match
Service Manual
PRODUCT
10
¾ Cozy
Model
GWH(07)MA-K
3DNA3E/I
GWH(09)MA-K
3DNA3E/I
GWH(12)MB-K
3DNA3E/I
GWH(18)MC-K
3DNA3E/I
Cooling kW 2.1 2.6 3.5 5.3
Capacity
Heating kW 2.6 2.8 3.8 5.8
Power supply V-Ph-Hz 220~240-1-50 220~240-1-50 220~240-1-50 220~240-1-50
Motor power input kW 0.03 0.03 0.04 0.045
m
3
/h 450 500 630 850
Air flow volume
CFM 265 294 371 500
Sound pressure level
(SH/H/M/L)
dB(A) 36/34/31/28/- 37/34/31/28/- 38/34/32/30/- 46/43/40/36/-
Output kW 0.01 0.01 0.02 0.02
Fan motor
Running
current
A 0.14 0.14 0.22 0.31
Gas inch 3/8″(Φ9.52mm) 3/8″(Φ9.52mm) 3/8″(Φ9.52mm) 1/2″(Φ12.7mm)
Liquid inch 1/4″(Φ6.35mm) 1/4″(Φ6.35mm) 1/4″(Φ6.35mm) 1/4″(Φ6.35mm)
Connecting
pipe
Connection method Flare Connection Flare Connection Flare Connection Flare Connection
External
dia.
mm Φ20 Φ20 Φ20 Φ20
Drain pipe
Thickness mm 1.5 1.5 1.5 1.5
Outline
dimension
W×D×H mm 790×170×265 790×170×265 845×180×275 940×200×298
Package
dimension
W×D×H mm 873×251×370 873×251×370 918×258×370 1013×288×395
Net Weight/ Gross weight kg 9/11 9/11 10/12.5 13/16
20'GP 348 348 336 254
40' GP 732 732 684 541
Loading quantity
40' HQ 852 852 798 609
Notes:
a. The rated cooling capacity data is measured under the following work condition: Indoor Temperature is 27℃
DB, 19℃WB. Outdoor Temperature is 35℃DB. The rated heating capacity data is measured under the following
work condition: Indoor Temperature is 20℃DB. Outdoor Temperature is 7℃DB, 6℃WB.
b. The data will change with the change of products. Refer to those parameters listed on nameplate.
c. Noise was tested in semi-silenced room, so the actual noise value will be a little higher for change of ambient.
