Super Free Match
Service Manual
PRODUCT
11
¾ Change
Model
GWH(07)KF-K
3DNA6E/I
GWH(09)KF-K
3DNA6E/I
GWH(12)KF-K
3DNA6E/I
GWH(18)KG-K
3DNA6E/I
Cooling kW 2.1 2.6 3.5 5.3
Capacity
Heating kW 2.6 2.8 3.8 5.8
Power supply V-Ph-Hz 220~240-1-50 220~240-1-50 220~240-1-50 220~240-1-50
Motor power input kW 0.03 0.03 0.03 0.06
m
3
/h 550 600 680 800
Air flow volume
CFM 324 353 400 471
Sound pressure level
(SH/H/M/L)
dB(A) 40/38/30/24/- 41/38/30/24/- 42/39/31/25/- 45/40/37/32/-
Output kW 0.01 0.01 0.01 0.02
Fan motor
Running
current
A 0.16 0.16 0.16 0.31
Gas inch 3/8″(Φ9.52mm) 3/8″(Φ9.52mm) 3/8″(Φ9.52mm) 1/2″(Φ12.7mm)
Liquid inch 1/4″(Φ6.35mm) 1/4″(Φ6.35mm) 1/4″(Φ6.35mm) 1/4″(Φ6.35mm)
Connecting
pipe
Connection method
Flare
Connection
Flare
Connection
Flare
Connection
Flare
Connection
External dia. mm Φ20 Φ20 Φ20 Φ20
Drain pipe
Thickness mm 1.5 1.5 1.5 1.5
Outline
dimension
W×D×H mm 770×201×283 770×201×283 770×201×283 865×215×305
Package
dimension
W×D×H mm 847×264×357 847×264×357 847×264×357 948×298×395
Net Weight/ Gross weight kg 8/10 8/10 9/11 12/15
20'GP 328 328 328 264
40' GP 688 688 688 542
Loading quantity
40' HQ 774 774 774 616
Notes:
a. The rated cooling capacity data is measured under the following work condition: Indoor Temperature is 27℃
DB, 19℃WB. Outdoor Temperature is 35℃DB. The rated heating capacity data is measured under the following
work condition: Indoor Temperature is 20℃DB. Outdoor Temperature is 7℃DB, 6℃WB.
b. The data will change with the change of products. Refer to those parameters listed on nameplate.
c. Noise was tested in semi-silenced room, so the actual noise value will be a little higher for change of ambient.
