Super Free Match
Service Manual
PRODUCT
12
¾ Viola
Model GWH(07)RA-K3DNA3E/I GWH(09)RA-K3DNA3E/I
Cooling kW 2.1 2.6
Capacity
Heating kW 2.6 2.8
Power supply V-Ph-Hz 220~240-1-50 220~240-1-50
Motor power input kW 0.03 0.03
m
3
/h 500 500
Air flow volume
CFM 294 294
Sound pressure level (SH/H/M/L) dB(A) 40/37/35/32/- 40/37/35/32/-
Output kW 0.01 0.01
Fan motor
Running current A 0.14 0.14
Gas inch 3/8″(Φ9.52mm) 3/8″(Φ9.52mm)
Liquid inch 1/4″(Φ6.35mm) 1/4″(Φ6.35mm)
Connecting pipe
Connection method Flare Connection Flare Connection
External dia. mm Φ20 Φ20
Drain pipe
Thickness mm 1.5 1.5
Outline dimension W×D×H mm 794×186×265 794×186×265
Package dimension W×D×H mm 873×270×353 873×270×353
Net Weight/ Gross weight kg 9/11.5 9/11.5
20'GP 348 348
40' GP 720 720
Loading quantity
40' HQ 840 840
