Super Free Match
Service Manual
PRODUCT
13
Model
GWH(12)RB-K3DN
A3E/I
GWH(18)RC-K3DN
A3E/I
GWH(24)RC-K3DN
A1A/I
Cooling kW 3.5 5.3 6.45
Capacity
Heating kW 3.8 5.8 7.1
Power supply V-Ph-Hz 220~240-1-50 220~240-1-50 220~240-1-50
Motor power input kW 0.05 0.06 0.065
m
3
/h 630 850 1000
Air flow volume
CFM 371 500 588
Sound pressure level
(SH/H/M/L)
dB(A) 42/39/36/33/- 45/42/37/33/- 48/46/44/42/-
Output kW 0.02 0.02 0.035
Fan motor
Running
current
A 0.22 0.31 0.31
Gas inch 3/8″(Φ9.52mm) 1/2″(Φ12.7mm) 5/8″(Φ15.9mm)
Liquid inch 1/4″(Φ6.35mm) 1/4″(Φ6.35mm) 3/8″(Φ9.52mm)
Connecting
pipe
Connection method Flare Connection Flare Connection Flare Connection
External dia. mm Φ20 Φ20 Φ20
Drain pipe
Thickness mm 1.5 1.5 1.5
Outline
dimension
W×D×H mm 848×189×274 945×208×298 1018×223×315
Package
dimension
W×D×H mm 926×279×359 1013×300×383 1086×328×398
Net Weight/ Gross weight kg 10/12.5 13/16 15.5/20.5
20'GP 306 254 174
40' GP 636 541 366
Loading quantity
40' HQ 742 609 427
Notes:
a. The rated cooling capacity data is measured under the following work condition: Indoor Temperature is 27℃
DB, 19℃WB. Outdoor Temperature is 35℃DB. The rated heating capacity data is measured under the following
work condition: Indoor Temperature is 20℃DB. Outdoor Temperature is 7℃DB, 6℃WB.
b. The data will change with the change of products. Refer to those parameters listed on nameplate.
c. Noise was tested in semi-silenced room, so the actual noise value will be a little higher for change of ambient.
