Super Free Match
Service Manual
PRODUCT
14
4.2.2 Duct type
Model Heat pump
GFH(09)EA-K3D
NA1A/I
GFH(12)EA-K3D
NA1A/I
GFH(18)EA-K3D
NA1A/I
Cooling KW 2.50 3.50 5.00
Capacity
Heating KW 2.80 3.85 5.50
Power supply V-Ph-Hz 220~240-1-50 220~240-1-50 220~240-1-50
Motor power input kW 0.065 0.075 0.08
m3/h 450 500 700
Air flow volume
CFM 265 294 412
Sound pressure level (H/L) dB(A) 37/31 39/32 41/33
Output kW 0.03 0.04 0.05
Fan motor
Running current A 0.28 0.31 0.41
Gas inch 3/8″(Φ9.52mm) 3/8″(Φ9.52mm) 1/2″(Φ12.7mm)
Liquid inch 1/4″(Φ6.35mm) 1/4″(Φ6.35mm) 1/4″(Φ6.35mm)
Connecting pipe
Connection method Flare Connection Flare Connection Flare Connection
External dia. mm Φ31 Φ31 Φ31
Drain pipe
Thickness mm 3 3 3
Outline dimension W×D×H mm 700×615×200 700×615×200 900×615×200
Package dimension W×D×H mm 893×743×305 893×743×305 1123×743×305
Net Weight/ Gross weight kg 22/27 23/29 27/36
20'GP 108 108 90
40' GP 234 234 180
Loading quantity
40' HQ 234 234 180
