Super Free Match
Service Manual
PRODUCT
15
Model Heat pump GFH(21)EA-K3DNA1A/I GFH(24)EA-K3DNA1A/I
Cooling KW 6.00 7.10
Capacity
Heating KW 6.60 8.00
Power supply V-Ph-Hz 220~240-1-50 220~240-1-50
Motor power input kW 0.11 0.11
m3/h 1000 1000
Air flow volume
CFM 588.5 588.5
Sound pressure level dB(A) 42/34 42/34
Output kW 0.061 0.061
Fan motor
Running current A 0.5 0.5
Gas inch 5/8″(Φ15.9mm) 5/8″(Φ15.9mm)
Liquid inch 3/8″(Φ9.52mm) 3/8″(Φ9.52mm)
Connecting pipe
Connection method Flare Connection Flare Connection
External dia. mm Φ31 Φ31
Drain pipe
Thickness mm 3 3
Outline dimension W×D×H mm 1100×615×200 1100×615×200
Package dimension W×D×H mm 1323×743×305 1323×743×305
Net Weight/ Gross weight kg 31/41 31/41
20'GP 72 72
40' GP 162 162
Loading quantity
40' HQ 162 162
Notes:
a. The rated cooling capacity data is measured under the following work condition: Indoor Temperature is 27℃
DB, 19℃WB. Outdoor Temperature is 35℃DB. The rated heating capacity data is measured under the following
work condition: Indoor Temperature is 20℃DB. Outdoor Temperature is 7℃DB, 6℃WB.
b. The data will change with the change of products. Refer to those parameters listed on nameplate.
c. Noise was tested in semi-silenced room, so the actual noise value will be a little higher for change of ambient.
