4.2.3 Cassette
Model Heat pump GKH(12)BA-K3DNA2A/I GKH(18)BA-K3DNA2A/I
Cooling KW 3.50 4.50
Capacity
Heating KW 4.00 5.00
Power supply V-Ph-Hz 220~240-1-50 220~240-1-50
Motor power input kW 0.05 0.05
m3/h 600 600
Air flow volume
CFM 353 353
Sound pressure level(H/L) dB(A) 46/42 46/42
Output kW 0.011 0.011
Fan motor
Running current A 0.23 0.23
Gas inch 3/8″(Φ9.52mm) 1/2″(Φ12.7mm)
Liquid inch 1/4″(Φ6.35mm) 1/4″(Φ6.35mm)
Connecting
pipe
Connection method Flare Connection Flare Connection
External dia. mm Φ31 Φ31
Drain pipe
Thickness mm 3 3
Body
W×D×H
mm 570×570×230 570×570×230
Outline
dimension
Panel
W×D×H
mm 650×650×50 650×650×50
Body
W×D×H
mm 851×731×325 851×731×325
Package
dimension
Panel
W×D×H
mm 733×673×117 733×673×117
Body Net Weight/Gross weight kg 18.0/23.0 18.0/23.0
Panel Net Weight/Gross weight kg 2.5/3.5 2.5/3.5
20'GP 102 102
40'GP 209 209
Loading quantity
40'HQ 246 246
