Super Free Match
Service Manual
PRODUCT
19
4.2.5 Console type
Model Heat pump
GEH(09)AA-K3DNA1
C/I
GEH(12)AA-K3DNA1
C/I
GEH(18)AA-K3DNA1
C/I
Cooling KW 2.6 3.5 5.3
Capacity
Heating KW 2.8 3.8 5.8
Power supply V-Ph-Hz 220~240-1-50 220~240-1-50 220~240-1-50
Motor power input kW 0.05 0.05 0.05
m3/h 500 600 650
Air flow volume
CFM 294 353 383
Sound pressure level
(SH/H/MH/M/ML/L/SL)
dB(A) 40/38/36/33/30/27/25 42/40/38/37/35/32/25 48/46/44/41/37/35/32
Output kW 0.03 0.03 0.03
Fan motor
Running
current
A 0.14 0.14 0.14
Gas inch 3/8″(Φ9.52mm) 3/8″(Φ9.52mm) 1/2″(Φ12.7mm)
Liquid inch 1/4″(Φ6.35mm) 1/4″(Φ6.35mm) 1/4″(Φ6.35mm)
Connecting
pipe
Connection method Flare Connection Flare Connection Flare Connection
External
dia.
mm Φ20 Φ20 Φ20
Drain pipe
Thickness mm 1.5 1.5 1.5
Outline
dimension
W×D×H mm 700×215×600 700×215×600 700×215×600
Package
dimension
W×D×H mm 791×286×710 791×286×710 791×286×710
Net Weight/Gross weight kg 15/18 15/18 15/18
20'GP 168 168 168
40' GP 348 348 348
Loading quantity
40' HQ 440 440 440
Notes:
a. The rated cooling capacity data is measured under the following work condition: Indoor Temperature is 27℃
DB, 19℃WB. Outdoor Temperature is 35℃DB. The rated heating capacity data is measured under the following
work condition: Indoor Temperature is 20℃DB. Outdoor Temperature is 7℃DB, 6℃WB.
b. The data will change with the change of products. Refer to those parameters listed on nameplate.
c. Noise was tested in semi-silenced room, so the actual noise value will be a little higher for change of ambient.
