Super Free Match
Service Manual
PRODUCT
18
4.2.4 Floor ceiling type
Model Heat pump
GTH(09)BA-K3
DNA1A/I
GTH(12)BA-K3
DNA1A/I
GTH(18)BA-K3
DNA1A/I
GTH(24)BA-K3
DNA1A/I
Cooling KW 2.50 3.50 5.00 7.10
Capacity
Heating KW 2.80 3.85 5.50 8.00
Power supply V-Ph-Hz 220~240-1-50 220~240-1-50 220~240-1-50 220~240-1-50
Motor power input kW 0.055 0.055 0.11 0.11
m3/h 650 650 950 1250
Air flow volume
CFM 382.5 382.5 559 736
Sound pressure level
(H/L)
dB(A) 40/36 40/36 45/40 48/44
Output kW 0.015 0.015 0.02 0.05
Fan motor
Running
current
A 0.3 0.3 0.5 0.5
Gas inch 3/8″(Φ9.52mm) 3/8″(Φ9.52mm) 1/2″(Φ12.7mm) 5/8″(Φ15.9mm)
Liquid inch 1/4″(Φ6.35mm) 1/4″(Φ6.35mm) 1/4″(Φ6.35mm) 3/8″(Φ9.52mm)
Connecting
pipe
Connection method Flare Connection Flare Connection Flare Connection Flare Connection
External
dia.
mm Φ17 Φ17 Φ17 Φ17
Drain pipe
Thickness mm 1.75 1.75 1.75 1.75
Outline
dimension
W×D×H mm 1220×700×225 1220×700×225 1220×700×225 1220×700×225
Package
dimension
W×D×H mm 1343×823×315 1343×823×315 1343×823×315 1343×823×315
Net Weight/Gross weight kg 40/50 40/50 40/50 45/54
20'GP 66 66 66 66
40' GP 132 132 132 132
Loading quantity
40' HQ 132 132 132 132
Notes:
a. The rated cooling capacity data is measured under the following work condition: Indoor Temperature is 27℃
DB, 19℃WB. Outdoor Temperature is 35℃DB. The rated heating capacity data is measured under the following
work condition: Indoor Temperature is 20℃DB. Outdoor Temperature is 7℃DB, 6℃WB.
b. The data will change with the change of products. Refer to those parameters listed on nameplate.
c. Noise was tested in semi-silenced room, so the actual noise value will be a little higher for change of ambient.
