Gree GMV-120WM/B-F Service Manual

GMV5 D.C INVERTER MULTI VRF SERVICE MANUAL
253
64
147.2
4.289
2.717
160
320
0.2891
3.253
65
149
4.14
2.734
4.2.2.3 Voltage list of 50 kΩ discharge temperature sensors (including top temperature sensor, and
discharge air temperature sensor)
Temperature
Resistance
Voltage
Temperature
Resistance
Voltage
°C
℉
kΩ
V
°C
℉
kΩ
V
-30
-22
911.56
0.036
61
141.8
11.736
1.518
-29
-20.2
853.66
0.038
62
143.6
11.322
1.548
-28
-18.4
799.98
0.041
63
145.4
10.925
1.577
-27
-16.6
750.18
0.043
64
147.2
10.544
1.606
-26
-14.8
703.92
0.046
65
149
10.178
1.635
-25
-13
660.93
0.049
66
150.8
9.8269
1.664
-24
-11.2
620.94
0.052
67
152.6
9.4896
1.693
-23
-9.4
583.72
0.056
68
154.4
9.1655
1.722
-22
-7.6
549.04
0.059
69
156.2
8.9542
1.741
-21
-5.8
516.71
0.063
70
158
8.5551
1.778
-20
-4
486.55
0.066
71
159.8
5.9676
1.806
-19
-2.2
458.4
0.07
72
161.6
7.9913
1.834
-18
-0.4
432.1
0.075
73
163.4
7.7257
1.862
-17
1.4
407.51
0.079
74
165.2
7.4702
1.889
-16
3.2
384.51
0.084
75
167
7.2245
1.916
-15
5
362.99
0.088
76
168.8
6.9882
1.943
-14
6.8
342.83
0.094
77
170.6
6.7608
1.969
-13
8.6
323.94
0.099
78
172.4
6.542
1.995
-12
10.4
306.23
0.104
79
174.2
6.3315
2.021
-11
12.2
289.61
0.11
80
176
6.1288
2.046
-10
14
274.02
0.116
81
177.8
5.9336
2.071
-9
15.8
259.37
0.123
82
179.6
5.7457
2.096
-8
17.6
245.61
0.129
83
181.4
5.5647
2.12
-7
19.4
232.67
0.136
84
183.2
5.3903
2.144
-6
21.2
220.5
0.143
85
185
5.2223
2.168
-5
23
209.05
0.151
86
186.8
5.0605
2.191
-4
24.8
195.97
0.158
87
188.6
4.9044
2.214
-3
26.6
188.12
0.167
88
190.4
4.7541
2.237
-2
28.4
178.65
0.175
89
192.2
4.6091
2.259
-1
30.2
169.68
0.184
90
194
4.4693
2.281
0
32
161.02
0.193
91
195.8
4.3345
2.302
1
33.8
153
0.202
92
197.6
4.2044
2.323
2
35.6
145.42
0.212
93
199.4
4.0789
2.344
3
37.4
135.96
0.223
94
201.2
3.9579
2.364
4
39.2
131.5
0.233
95
203
3.841
2.384
5
41
126.17
0.242
96
204.8
3.7283
2.404
6
42.8
119.08
0.256
97
206.6
3.6194
2.423
7
44.6
113.37
0.267
98
208.4
3.5143
2.442
