Gree GMV-24WL/C-T

GREE DC Inverter Side Discharge VRF Ⅱ for North America
126
Removal operation for panel
Remark: Before removing the panel, please make sure that the unit is disconected with the power
Process
Operation Instruction
4. Remove left
side plate and
rear side plate
Loose screws fixing
left side plate and rear
side plate with
screwdriver
remove the rear side
plate
Removal operation for blade
Remark: Before removing the motor, please make sure that the unit is disconnected with the power.
Process
Operation Instruction
1. Remove grille
Loose screws fixing
the panel with
screwdriver
Then remove the
grille
2. Remove
blade
Loosen nuts fixing
the blade with
wrench
Then remove the
blade and put it on
the floor flatly
