Gree GMV-24WL/C-T Service Manual

GREE DC Inverter Side Discharge VRF Ⅱ for North America
70
Unit:mm（inch）
Model
A
B
C
D
E
GMV-36WL/A-T(U)
GMV-48WL/A-T(U)
900
（
35 7/16
）
340
（
13 3/8
）
1345
（
53
）
572
（
22 1/2
）
378
（
15
）
GMV-60WL/A-T(U)
940
(37)
320
(12 9/16)
1430
(56 1/4)
632
(24 7/8)
350
(14 7/8)
GMV-36WL/C-T(U)
GMV-48WL/C-T(U)
900
（
35 3/8
）
340
(13 3/8)
1345
(53)
572
(22 1/2)
378
(15)
GMV-60WL/C-T(U)
940
(37)
320
(12 9/16)
1430
(56 1/4)
632
(24 7/8)
350
(14 7/8)
3.7 Installation space requirement
If all sides of the ODU (including the top) are surrounded by walls, process according to the
following requirements for installation space:
Fig.3 Fig.4
4 Installation of Electronic Expansion Valve Assy (unit with
external EXV)
The EXV of indoor unit is built-in.
5 Installation of Refrigerant Pipeline
5.1Allowable Length and Height Difference of Connection Pipe
Y type branch joint is adopted to connect indoor and outdoor units. Connecting method is shown in
the figure below:
NOTICE!
Equivalent length of one Y-type branch is 0.5m(1-5/8feet).
