Gree GMV-24WL/C-T Service Manual

GREE DC Inverter Side Discharge VRF Ⅱ for North America
141
NO.
Name of Part
GMV-36WL/A-T(U)/
GMV-48WL/A-T(U)
GMV-60WL/A-T(U)
Product Code
CN850W0230/
CN850W0220
Product Code
CN850W0270
11
Left Side Plate
01314100013P
1
01314100084
1
12
Clapboard
01244100005
1
01244100029
1
13
Fan Motor
15704115
1
1570280206
1
14
Sensor Sub-Assy
39008000061G
1
39008000061G
1
15
Fan Motor
1570411501
1
1570280201
1
16
Front Grill
01574100009
2
01572800003
2
17
Cabinet
01514100002P
1
01514100013P
1
18
Front Side Plate
01314100012P
1
01314100082P
1
19
Handle
26235253
1
26904100016
1
20
Front Connection Board
01344100002P
1
01314100082P
1
21
Diversion Circle
10474100001
2
10474100003
2
22
Axial Flow Fan
1043410000301
2
10434100006
2
23
Chassis Assy
01194100061
1
209058000001
1
24
Motor Support
Sub-Assy
01805200260
1
017012000006
1
25
Pressure Protect
Switch
4602000902
1
4602000902
1
26
Discharge Tube
Sub-Assy
04534100057
1
030013000052
1
27
Silencer
07444105
1
/
28
Oil Separator
07424105
1
07424105
1
29
Compressor and
Fittings
0020410000102
1
00209400005
1
30
Electrical
Heater(Compressor)
765152128
1
765152128
1
31
Cut off Valve
07330000002
1
07334100011
1
32
Strainer
07212001
1
0721200102
1
33
Gas-liquid Separator
07424100014
1
07424140
1
34
Electrical Heater
765100047
1
765100047
1
35
Capillary Sub-Assy
04004100023
1
030006000087
1
36
Strainer
07415200002
2
07415200002
3
37
Electromagnetic Valve
43000054
1
43000054
1
38
Magnet Coil
4304000417
1
4304000416
1
39
Right Connection Board
01344100003P
1
01344100059P
1
40
Rear Side Plate
Sub-Assy
01314100011P
1
01314100083P
1
41
Sensing Device
322101002
1
322101002
1
42
Sensor (High Pressure)
322101032
1
322101034
1
43
Gas By-pass Sub- Assy
04534100056
1
030082000003
1
44
Cut off Valve
07330000002
1
07334100054
1
45
Plate-type Heat
Exchanger Assy
00904100013
1
007023000001
1
46
Discharge Charge
07133771
1
07133771
1
