GREE Multi Variable Air Conditioners Indoor Unit
101
3.4.2 Installation Space
>3000(118-1/9)
>150(6)
>150(6)
>150(6)
>2500(98-3/7)
3.4.3 Installation Notice
(1) Installation dimension (refer to the outline dimension in the figure shown above).
(2) Installation foundation.
Make sure the top hanger has sufficient strength to withstand the weight of unit.
(3) Installation site and environment.
1) Keep the unit from insolation and rainch
2) Water can be drained from drainage pipe conveniently.
3) Keep the unit from fire, flammable objects, corrosive gap or exhaust gas.
4) There can’t be any obstacle at air inlet and air outlet to in order to keep good ventilation.
5) Please reserve sufficient space for maintenance.
6) Please take proper measures to reduce noise and vibration.
3.4.4 Electrical Installation of Unit
All electrical installation must be done by professionals according to national and local laws and
regulations.
The unit must be grounded reliably according to related requirements.
Please connect wire according to the wiring diagram on the unit.
To Next Page
