Gree GMV-ND07PLS/A-T(U) - Fresh Air Processing Type Indoor Unit

GREE Multi Variable Air Conditioners Indoor Unit
218
5.7 Fresh Air Processing Type Indoor Unit
Exploded View of GMV-NDX42P/A-T(U) / GMV-NDX48P/A-T(U)
No.
Name of part
For the following unit
For the following unit
Unit
Product Code
Unit
Product Code
GMV-NDX42P/A-T(U)
CM810N1250
GMV-NDX48P/A-T(U)
CM810N1030
Part code
Quantity
Part code
Quantity
1
Filter Sub-Assy
111001000052
3
111001000052
3
2
Return Air Frame
Sub-Assy
017026000003
1
017026000003
1
3
Propeller Housing(Upper)
26905200078
3
26905200078
3
4
Fan Bearing
76512210
1
76512210
1
5
Propeller Housing(Lower)
26905200079
3
26905200079
3
6
Brushless DC Motor
1570940000601
1
1570940000601
1
7
Centrifugal Fan
10455200003
3
10455200003
3
8
Joint Slack
73018731
1
73018731
1
9
Centrifugal Fan Assy
000052000028
1
000052000028
1
10
Choke plug of Drain pipe
76815214
2
76815214
2
11
Cover plate (Air Ruturn)
01265200123
1
01265200123
1
12
Bottom Cover Plate
01265200125
1
01265200125
1
13
Left Side Plate Assy
01315200147
1
01315200147
1
14
Hook
02112466
4
02112466
4
15
Seal Plate
01495200043
1
01495200043
1
16
Reactor
43138000047
1
43138000047
1
17
Terminal Board
4201115404
1
4201115404
1
18
Terminal Board
4201800002601
1
4201800002601
1
19
Main Board
300002000686
2
300002000686
2
