GREE Multi Variable Air Conditioners Indoor Unit
219
No.
Name of part
For the following unit
For the following unit
Unit
Product Code
Unit
Product Code
GMV-NDX42P/A-T(U)
CM810N1250
GMV-NDX48P/A-T(U)
CM810N1030
Part code
Quantity
Part code
Quantity
20
Electric Box Assy
100002003006
1
100002003006
1
21
Air Outlet Frame Assy
01375200023
1
01375200023
1
22
Evaporator Assy
011001000471
1
011001000471
1
23
Electic Expand Valve
Fitting
4304413215
1
4304413215
1
24
Strainer
0741410000601
1
0741410000601
1
25
Electronic Expansion
Valve
07334468
1
07334468
1
26
Strainer
7415210
1
7415210
1
27
Foam Sub-Assy(Water
Tray)
12505200021
1
12505200021
1
28
Top Cover Board Assy
01264100105
1
01264100105
1
29
Right Side Plate Assy
01315200148
1
01315200148
1
30
Display Board
30296000040
1
30296000040
1
31
Temperature Sensor
3900005910
1
3900005910
1
32
Temperature Sensor
390000592
1
390000592
1
33
Temperature Sensor
390000454
1
390000454
1
34
Temperature Sensor
390002072
1
390002072
1
35
Drain Hose Sub-Assy
05232050
1
05232050
1
36
Corrugated Pipe
05015408
1
05015408
1
Above data is subject to change without notice, please refer the SP in global service website.
Exploded View of GMV-NDX54P/A-T(U) / GMV-NDX72P/A-T(U) / GMV-NDX96P/A-T(U):
