GREE Multi Variable Air Conditioners Indoor Unit
180
Motor and fan
Step
Diagram
Operation Procedure
(6) Remove
the
evaporator.
Remove the evaporator.
(7) Unscrew
the motor
pressing
board.
Use a screwdriver to unscrew
the motor pressing board.
(8) Remove
the
pressing
board and
replace the
motor.
Remove the pressing board and
replace the motor.
(9) Screw the
motor
pressing
board.
Use a screwdriver to screw the motor
pressing board.
(10) Install the
evaporator.
Install the evaporator.
(11) Screw the
outlet
board.
Use a screwdriver to screw the outlet
board.
