Gree GMV-ND07PLS/A-T(U) - Page 216

GREE Multi Variable Air Conditioners Indoor Unit
210
No.
Name of part
For the following unit
For the following unit
Unit
Product Code
Unit
Product Code
GMV-ND09ZD/A-T(U)
CM600N0420
GMV-ND12ZD/A-T(U)
CM600N0430
Part code
Quantity
Part code
Quantity
1
Sensor Sub-assy
39008000101G
1
39008000101G
1
2
Connection Board
02229406
1
02229406
1
3
Right Cover Plate
26909444
1
26909444
1
4
Plate Board of Water
Releasing Flume
26909442
1
26909442
1
5
Installation Supporting
Frame
01809402
1
01809402
1
6
Axile Bush
10542704
2
10542704
2
7
Right Side Plate Sub-Assy
01319429
1
01319429
1
8
Water Releasing Flume
02284106P
1
02284106P
1
9
Connection Board
01344115
1
01344115
1
10
Electronic Expansion
Valve
07334463
1
07334463
1
11
Strainer
0741410000601
2
0741410000601
2
12
Guide Louver
10619403
2
10619403
2
13
Front Connection Board
01349414P
1
01349414P
1
14
Air Louver
10619404
16
10619404
16
15
Rotating Shaft
26909430
4
26909430
4
16
Guide Louver Supporter
Sub-Assy
0180941601
1
0180941601
1
17
Fixed Mount
26909426R
1
26909426R
1
18
Display Board
30294000009
1
30294000009
1
19
Rear Side Plate Assy
01319400008
1
01319400008
1
20
Evaporator Assy
01024100126
1
01024100096
1
21
Rotating Shaft
26909413
1
26909413
1
22
Connecting Rod
26909411
1
26909411
1
23
Rotating Shaft
26909412
1
26909412
1
24
Stepping Motor
1521240206
1
1521240206
1
25
Installation Supporting
Frame
01809401
1
01809401
1
26
Left Side Plate Sub-Assy
01319428
1
01319428
1
27
Electric Box Assy
01394100587
1
01394100587
1
28
Main Board
30226000029
1
30226000029
1
29
Electric Box Cover
01429420
1
01429420
1
30
Left Cover Plate
2690944302
1
2690944302
1
31
Terminal Board
42011106
1
42011106
1
32
Terminal Board
4201800002601
1
4201800002601
1
33
Mid-clapboard sub-assy
01249400004
1
01249400004
1
34
Support Of Motor Bearing
01792408
2
01792408
2
35
O-Gasket of Bearing
76512404
2
76512404
2
36
Rotary Axis Sub-Assy
73018000037
2
73018000037
2
37
Centrifugal Fan
10425200
4
10425200
4
38
Joint Slack
73018731
2
73018731
2
39
Supporter
01809400002
1
01809400002
1
40
Fan Motor
15704100001
1
15704100001
1
41
Supporter
01809400001
1
01809400001
1
42
Rear Connection board
01349422
1
01349422
1
