GREE Multi Variable Air Conditioners Indoor Unit
216
No.
Name of part
For the following unit
Unit
Product Code
GMV-ND36ZD/A-T(U)
CM600N0470
GMV-ND42ZD/A-T(U)
CM600N0480
GMV-ND48ZD/A-T(U)
CM600N0490
Part code
Quantity
1
Remote Controller
30510589
1
2
Sensor Sub-assy
39008000100G
1
3
Water Tray Assy
01289401
1
4
Air Louver
26909418
24
5
Connection Board
02229406
1
6
Right Cover Plate
26909422
1
7
Installation Supporting
Frame
01809402
1
8
Right Side Plate Sub-Assy
01319408
1
9
Right Foam Assy
12509425
1
10
Axile Bush
10542704
2
11
Plate Board of Water
Releasing Flume
26909442
1
12
Water Releasing Flume
26909441
1
13
connected board
(evaporator)
01344108
1
14
Strainer
0741410000601
2
15
Electronic Expansion Valve
07334468
1
16
Electric expand valve fitting
4304413203
1
17
Rotating Shaft
26909430
6
18
Supporter
26909409
3
19
Evaporator Assy
01024100105
1
20
Guide Louver
10619405
2
21
Front Connection Board
01349404P
1
22
Fixed Mount
26909426R
1
23
Display Board
30294000009
1
24
Rear Side Plate Sub-Assy
01319442
1
25
Front Connection Board
Foam Assy
12509434
1
26
Water Releasing Flume
02289402P
1
27
Stepping Motor
1521240206
2
28
Left Foam Assy
12509437
1
29
Electric Box Assy
01394100586
1
30
Electric Box Cover
01429410P
1
31
Installation Supporting
Frame
01809421
1
32
Left Cover Plate
2690941601
1
