Gree GMV-ND07PLS/A-T(U) User Manual

GREE Multi Variable Air Conditioners Indoor Unit
244
Exploded View of GMV-ND72PH/B-T(U) / GMV-ND96PH/B-T(U):
2 3 4 5 6 7 8 12
15 16
1 9 10 11 13
14
23 22 21 20
17
1819
2425
No.
Model
GMV-ND72PH/B-T(U)
Qty.
Product Code
CM810N1600
Part Name
Part Code
1
Front Side Plate Sub-Assy
017101060001
1
2
Motor for Centrifugal Fan
103004000106
1
3
Brushless DC Motor
15704100009
1
4
Motor for Centrifugal Fan
103004000105
1
5
Bottom Cover Plate
012147060003
2
6
Bottom Cover Plate
012147060002
1
7
Water Tray Assy
000069060003
1
8
Hook
02112466
4
9
Right Side Plate
012056060002
1
10
Electric Box Assy
100002060073
1
11
Radiator
49018000068
1
12
Main Board
30226000092
1
