Gree GMV-ND07PLS/A-T(U) - Page 255

GREE Multi Variable Air Conditioners Indoor Unit
249
NO.
Model
GMV-ND36A/A-T(U)
GMV-ND42A/A-T(U)
Qty.
Product Code
CM810N0700
CM810N0690
Part Name
Part Code
21
Terminal Board
4201115402
1
22
Terminal Board
4201800002601
1
23
Terminal Board
42011147
1
24
Main Board
300002000321
1
25
Terminal Board
42011103
1
26
Transformer
43110286
1
27
Top Cover Plate Sub-assy
01262200013
1
28
Left Side Plate Sub-assy
01312200015
1
29
Sensor Sub-assy
39008000103G
1
30
Display Board
30296000040
1
Exploded View of GMV-ND48A/A-T(U) / GMV-ND54A/A-T(U)
NO.
Model
GMV-ND48A/A-T(U)
GMV-ND54A/A-T(U)
Qty.
Product Code
CM810N0680
CM810N0710
Part Name
Part Code
1
insulating board
75142201
1
2
Lower cover plate 1
01264100065
1
3
Top Cover Board Sub-assy
01262200024
1
4
Plastic Cover
26902209
4
5
Lower cover plate
sub-assy 2
01262200026
1
6
Evaporator Assy
01024100159
1
7
Current Divider
0722443501
1
8
Strainer
0721200101
2
9
Electronic Expansion
Valve
07334468
1
10
Electric Expand Valve
Fitting
4304413205
1
11
Secondary Water Tray
26902205
1
12
Choke Plug
76718209
8
13
Main water Tray
26902206
1
14
Filter Sub-Assy
11722202
1
15
Motor for Centrifugal Fan
1570220301
1
16
Fan Motor
150104000013
1
17
Right Side Plate Sub-Assy
01312200026
1
18
Rear Side Plate Sub-Assy
01312200028
1
19
Blower Mounting Plate
0132220001401
1
20
Electric cabinet board
100003000224
1
21
Terminal Board
4201115402
1
22
Terminal Board
4201800002601
1
23
Terminal Board
42011147
1
24
Main Board
300002000321
1
25
Terminal Board
42011103
1
26
Transformer
43110286
1
27
Top Cover Plate Sub-assy
01262200028
1
