Gree GMV-ND07PLS/A-T(U) - Page 257

GREE Multi Variable Air Conditioners Indoor Unit
251
NO.
Model
GMV-N12U/A-T(U)
Qty.
Product Code
CN750N0101
Part Name
Part Code
9
Electronic Expansion
Valve assy
030174000026
1
10
Strainer
0741410000601
2
11
Electronic Expansion
Valve
07334463
1
12
Electric Expand Valve
Fitting
4304413239
1
13
Display Board
30296000040
1
14
Sensor Sub-assy
39008000130G
1
Exploded View of GMV-N24U/A-T(U)
NO.
Model
GMV-N24U/A-T(U)
Qty.
Product Code
CN750N0061
Part Name
Part Code
1
Electric Box Assy
100002002825
1
2
Main Board
30226000081
1
3
Transformer
43110286
1
4
Terminal Board
4201115402
1
5
Terminal Board
4201025901
1
6
Terminal Board
42011154
1
7
Terminal Board
4201800002601
1
8
Terminal Board
42011147
1
9
Electronic Expansion
Valve assy
030174000027
1
10
Strainer
0741410000601
2
11
Electronic Expansion
Valve
07334466
1
12
Electric Expand Valve
Fitting
4304413239
1
13
Display Board
30296000040
1
14
Sensor Sub-assy
39008000130G
1
Exploded View of GMV-N48U/A-T(U)
NO.
Model
GMV-N48U/A-T(U)
Qty.
Product Code
CN750N0071
Part Name
Part Code
1
Electric Box Assy
100002002825
1
2
Main Board
30226000081
1
3
Transformer
43110286
1
4
Terminal Board
4201115402
1
5
Terminal Board
4201025901
1
6
Terminal Board
42011154
1
7
Terminal Board
4201800002601
1
8
Terminal Board
42011147
1
9
Electronic Expansion
Valve assy
43044100226
1
10
Strainer
0741410000601
2
11
Electronic Expansion
Valve
07334412
1
