Gree GMV-ND07PLS/A-T(U) User Manual

GREE Multi Variable Air Conditioners Indoor Unit
20
Model
GMV-ND07T
/A-T(U)
GMV-ND09T
/A-T(U)
GMV-ND12T
/A-T(U)
GMV-ND15T
/A-T(U)
GMV-ND18T
/A-T(U)
Refrigeration Control Device
EXV
EXV
EXV
EXV
EXV
Protection Device
Fuse
Fuse
Fuse
Fuse
Fuse
Panel Name
TC01
TC01
TC01
TC01
TC01
Model
GMV-ND24T
/A-T(U)
GMV-ND30T
/A-T(U)
GMV-ND36T
/A-T(U)
GMV-ND42T
/A-T(U)
GMV-ND48T
/A-T(U)
Product Code
CM500N0550
CM500N0560
CM500N0570
CM500N0580
CM500N0590
Cooling Capacity
Btu/h
24000
30000
36000
42000
48000
kW
7
8.8
10.6
12.3
14.1
Heating Capacity
Btu/h
27000
34000
40000
47000
54000
kW
7.9
10
11.7
13.8
15.8
Casing Finish
Galvanized Steel plate
Dimensions
(W×D×H)
Body Outline
mm
840×840×240
840×840×320
840×840×320
840×840×320
840×840×320
inch
33×33×9-1/2
33×33×12-5/8
33×33×12-5/8
33×33×12-5/8
33×33×12-5/8
Body Packaging
mm
963×963×325
963×963×409
963×963×409
963×963×409
963×963×409
inch
37-15/16
×37-15/16
×12-13/16
37-15/16
×37-15/16
×16-1/8
37-15/16
×37-15/16
×16-1/8
37-15/16
×37-15/16
×16-1/8
37-15/16
×37-15/16
×16-1/8
Panel Outline
mm
950×950×65
950×950×65
950×950×65
950×950×65
950×950×65
inch
37-3/8×37-3/8
×2-1/2
37-3/8×37-3/8
×2-1/2
37-3/8×37-3/8
×2-1/2
37-3/8×37-3/8
×2-1/2
37-3/8×37-3/8
×2-1/2
Panel
Packaging
mm
1033×1038
×133
1033×1038
×133
1033×1038
×133
1033×1038
×133
1033×1038
×133
inch
40-11/16
×40-7/8×5-1/4
40-11/16
×40-7/8×5-1/4
40-11/16
×40-7/8×5-1/4
40-11/16
×40-7/8×5-1/4
40-11/16
×40-7/8×5-1/4
Net Weight
Main Body
lbs.
58
72
72
72
72
kg
26.5
32.5
32.5
32.5
32.5
Panel
lbs.
15
15
15
15
15
kg
7
7
7
7
7
Gross
Weight
Main Body
lbs.
75
88
88
88
88
kg
34
40
40
40
40
Panel
lbs
24
24
24
24
24
kg
11
11
11
11
11
Pipe
Connections
Liquid Side
mm
Φ9.52
Φ9.52
Φ9.52
Φ9.52
Φ9.52
inch
Φ3/8
Φ3/8
Φ3/8
Φ3/8
Φ3/8
Gas Side
mm
Φ15.9
Φ15.9
Φ15.9
Φ15.9
Φ15.9
inch
Φ5/8
Φ5/8
Φ5/8
Φ5/8
Φ5/8
Drain Pipe
mm
Φ25
Φ25
Φ25
Φ25
Φ25
inch
Φ1
Φ1
Φ1
Φ1
Φ1
Power Supply
1-phase 208/230V 60Hz
Fan
Type × Quantity
Centrifugal×1
Centrifugal×1
Centrifugal×1
Centrifugal×1
Centrifugal×1
Driving Mechanism
Direct-driven
Direct-driven
Direct-driven
Direct-driven
Direct-driven
Motor Type
BLDC
BLDC
BLDC
BLDC
BLDC
Motor Power
Input
W
68
98
110
110
110
Motor Running
Current
A
0.5
0.8
0.9
0.9
0.9
Airflow
Rate(H/M/L)
CFM
695/590/470
885/795/650
1000/825/650
1095/885/680
1095/885/680
m
3
/h
1180/1000/800
1500/1350
/1100
1700/1400
/1100
1860/1500
/1150
1860/1500
/1150
